6-102617-1

集管和线壳 26P HDR DRRA SHRD

26 MODII HDR DRRA SHRD LF

Product Highlights

Header

Header Type = Shrouded

Number of Rows = Dual

Number of Positions = 26

Mating Post Length = 8.08 mm

得捷:
CONN HEADER R/A 26POS 2.54MM

贸泽:
集管和线壳 26P HDR DRRA SHRD

艾睿:
Easily mount this shrouded 6-102617-1 header connector from TE Connectivity onto your PCB project to support a variety of physical configuration options. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.54 mm. It has a right angle body orientation. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. The component will be shipped in tray format. This connector has an operating temperature of -55 to 105 °C. 6-102617-1 is housed in black thermoplastic. This product is 35.86 mm long, 10.49 mm tall and 16.23 mm deep. It uses the solder termination method.

安富利:
Conn Shrouded Header HDR 26 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Shrouded Header 4 Sides HDR 26 POS 2.54mm Solder RA Thru-Hole Tray

Newark:
# AMP - TE CONNECTIVITY  6-102617-1  26 MODII HDR DRRA SHRD LF New

MASTER:
MOD II, HDR SHROUDED, 4 SIDES, DBL ROW, .100X.100 C/L, RT, W/ .025 SQ POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
26 MODII HDR DRRA SHRD LF

Electro Sonic:
26 MODII HDR DRRA SHRD LF
