Use this unshrouded 67996-112HLF header connector from FCI where IDC ribbon cables are used. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. It has a maximum voltage rating of 1500 VAC. It has a header type gender. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This product is 15.24 mm long, 8.38 mm tall and 4.83 mm deep. 67996-112HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer. This connector has an operating temperature of -65 to 125 °C.
Connector Header Through Hole 12 position 0.100" 2.54mm
得捷:
CONN HEADER VERT 12POS 2.54MM
艾睿:
Use this unshrouded 67996-112HLF header connector from FCI where IDC ribbon cables are used. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. It has a maximum voltage rating of 1500 VAC. It has a header type gender. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This product is 15.24 mm long, 8.38 mm tall and 4.83 mm deep. 67996-112HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer. This connector has an operating temperature of -65 to 125 °C.
