Protect your printed circuit boards from accidental damages with FCI&s;s unshrouded 67997-172HLF header connector. This HDR connector&s;s 72 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. This is a 2-row connector. It has a maximum voltage rating of 1500 VAC. Its pitch is 2.54 mm. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 91.44 mm long, 8.38 mm tall and 4.83 mm deep. This connector has an operating temperature of -65 to 125 °C. It uses the solder termination method. 67997-172HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer.
针座连接器 通孔 72 位置 0.100"（2.54mm）
得捷:
CONN HEADER VERT 72POS 2.54MM
艾睿:
BergStik®, Board to Board connector, Unshrouded vertical header, Through Hole, Double Row, 72 Positions, 2.54 mm 0.100in Pitch
