HRP-150-15

Mean Well 150W 单输出 嵌入式开关模式电源 SMPS HRP-150-15, 120 → 370 V dc, 85 → 264 V ac输入

HRP-150 系列单输出电源，带 PFC 功能

高效、长寿命和高可靠性

空载功耗 <0.5W

内置有源 PFC 功能

内置恒定电流限制电路

内置远程感应功能

短路、过载、过电压和过温保护

可经受 300V 交流浪涌输入达 5 秒时间

1U 薄型 38mm

功率因数校正符合 EN61000-3-2,-3

EMC 符合 EN 55022 B 类

### 注

40°C 以上时功率开始下降。

平均故障间隔时间符合 MIL-HDBK-217F 标准。

### 标准

UL60950-1, TUV EN60950-1

### 认可

UL/cUL 认证，TUV，CB

欧时:
Mean Well 150W 单输出 嵌入式开关模式电源 SMPS HRP-150-15, 120 → 370 V dc, 85 → 264 V ac输入

贸泽:
开关电源 150W 15V 10A W/PFC Function

艾睿:
This HRP-150-15 AC to DC power supply from Mean-Well USA, Inc. safely converts alternating currents into direct currents that your electronic devices can make use of. It has a voltage of 15 V and maximum output power of 150 W. This part&s;s single output can handle a current up to 10 A. This part has a minimum operating temperature of -40 °C and a maximum of 70 °C.

Jameco:
AC to DC Power Supply Single Output 15 Volt 10 Amp 150 Watt

Chip1Stop:
AC/DC Power Supply Single-OUT 15V 10A 150W 13-Pin

TME:
Pwr sup.unit: switched-mode; modular; 150W; 15VDC; 10A; 85÷264VAC

MASTER:
AC/DC Power Supply Single-OUT 15V 10A 150W 13-Pin

Online Components:
AC/DC Power Supply - 1 Output - 15V@10A - 150W

Electro Sonic:
AC/DC Power Supply - 1 Output - 15V@10A - 150W

CDI:
AC/DC 150W 15V Single Output Power Supply, Enclosed
