Interface Mod; 2; Yellow; DIN Rail Mount; 280VAC/VDC; 15VDC; 22 to 12AWG;
Input/Output Opto Coupler Module, DIN Rail Mounting, 22 to 12 AWG Wire Size
Link incompatible systems, or expand the capabilities of your logic system with interface and electronic modules and carriers. These DIN rail- or panel-mounted printed circuit board modules and carriers give design flexibility, simplify panel layouts and reduce maintenance and downtime. Modules are supplied completely assembled, with ready to wire screw-cage clamp terminal blocks in an extruded track, and can be mounted on 35 or 32 mm DIN rail, or directly to panels. Order ready-made modules, or mount your own printed circuit boards into Altech mounting tracks. If your needs go beyond our comprehensive range of standard interface and electronic modules, Altech can custom design modules that meet even the most sophisticated requirements.
Provide a flexible, cost-effective transition between high-density connectors, and high-quality screw-cage clamp terminal blocks in communications, data processing, process control and other industrial applications. Equipped with component solder pads for easy insertion of circuit building components. DIN rail-mount, panel-mount available.
Mount standard optocoupler input/output I/O modules in a high-density arrangement for logic output to field devices, or for input of field data to the controller. Altech I/O carriers can accept up to 16 industry standard 0.6" 15.24 mm I/O modules in any combination — input, output, AC or DC from most manufacturers. 1-, 2- and 4-isolated position versions with 5, 15 and 24 VDC logic; and 4-, 8- and 16-bussed logic power versions with 5 to 24 VDC.
* Screw Cage Clamp Connector
* Integral Sockets, Retaining Nut
* Field Voltage Rating: 280 VAC/VDC
* LED Indicator, Fuse Protection
* DIN Rail-Mount, Panel-Mount Available
