ebm-papst 直流紧凑型和标准轴流风扇专业系列 ebm-papst 直流紧凑型和标准轴流风扇。叶轮材料为玻璃纤维强化塑料 PA 杆上排气,气流方向与各种轴承一致(球、套管、Sintec) 极性反接和锁定保护 ### 直流轴线
**Features:**
* New Super High Performance S-Force Fans Added to This Series
* DC Fans with Electronically Commutated External Rotor Motor
* Fully Integrated Commutation Electronics
* Electronic Protection Against Reverse Polarity, Blocking and Overloading by PTC Resistor, Partially Impedance Protected
* Air Intake Over Struts
* Rotational Direction CW Looking at Rotor
Metal Fan Housing
* Fiberglass Reinforced Plastic PA Impeller
* Electrical Connection Via Two Flat Pins 2.8 × 0.5 mm or 24 AWG, TR 64, 12.2 In. 310 mm Leads
电源电压DC 12.0 V
额定电压DC 12.0 V
额定功率 4.5 W
输入电压DC 12.0 V
功耗 4.9 W
工作温度Max 75 ℃
工作温度Min -30 ℃
额定电压 12 VDC
电源电压 12 VDC
安装方式 Through Hole
封装 Axial
长度 119 mm
宽度 119 mm
高度 38 mm
封装 Axial
材质 Metal
重量 390.09 g
工作温度 -30℃ ~ 75℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Bulk
制造应用 外壳, RAC, 工业驱动, 电源供给, 电信, 电子, 加热和通风
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8414596090
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
4182NX EBM-Papst | 当前型号 | 当前型号 |
4182NGX EBM-Papst | 完全替代 | 4182NX和4182NGX的区别 |
4184NX EBM-Papst | 功能相似 | 4182NX和4184NX的区别 |
MC36278 Multicomp | 功能相似 | 4182NX和MC36278的区别 |
