PLC I/O Module 6GK5 744 4 x I/O, 24V dc, 48V dc, 90 x 125 x 118mm
The Ethernet Client Modules from the SCALANCE W740 Product Line are Optimal for Integrating Industrial Ethernet Stations into Industrial Wireless LANs IWLANs for 2.4 GHz and 5 GHz with Transmission Rates of up to 54 Mbit/s.
Suitable for any application:
* SCALANCE W74x-1 for Installation in a Cabinet or Integration in Devices
* SCALANCE W74x-1PRO for Cabinet-free Installation
With the addition of a replaceable C-Plug memory disk, Access Points or Clients can be exchanged without a programming device. The configuration or application data are secured on the C-PLUG and can be implemented in another Scalance W devices without special know how.
**Features:**
* Wireless Client Module According to IEEE 802.11a/b/g for 2.4 or 5 GHz and up to 54 Mbit/s
* IEEE 802.11e for Wireless Multimedia WMM
* IEEE 802.11i for Security
* Modern Security Mechanisms e.g.WPA2, AES,IEEE 802.1x, RADIUS
* Support for One MAC/IP Device at the Ethernet Port
* Network and Port Address Translation NAT/PAT
**Specifications:**
* Low-Profile, Compact Aluminum Enclosure, Shock and Vibration-Proof for High Mechanical Requirements
* Construction and Design Suitable for Integration in a Device or for Installation in a Cabinet
* 2 × R-SMA Sockets for the Connection of Remote Antennas
* 1 × RJ45 Connection for 10/100 Mbit/s with Power-Over-Ethernet According to IEEE 802.3at Type 1 Corresponds to IEEE 802.3af
* 1 × 24 V DC Connection for Redundant Power In Feed
* 1 × C-PLUG Slot
* Function LEDs for Optical Signaling of Faults and Operating States
* Dust protection with IP30 Degree of Protection
* Temperature Range –20°C to +60°C
* Mounting: Wall or, with Optional Mounting Set, on S7 Mounting Rail, 35 mm Standard Mounting Rail
重量 0.29 kg
工作温度 20℃ ~ 60℃
Accessory Type Ethernet Client Module
Brand/Series 6GK Series
Current, Supply 0.23/0.12 A
Dimensions 100 W x 205 H x 20 D mm
Frequency 2.4/5 GHz
Mounting Type Wall
Number of Ports 6 Total [1 x Network Component and Terminal Network, 1 x Power Supply, 1 x Redundant Power Supply, 1 Radio Card, 2 x RSMA]
Port, Type 1 x Network Component and Terminal Network, 1 x Power Supply, 1 x Redundant Power Supply, 1 Radio Card, 2 x RSMA, RJ45
Power Loss 6/6 W
Primary Type Switches
Protection Class IP30
Protocol Type 10/100 Mbit/s
Special Features 2 Finger Classification, SNMP Management Option, May Power Cisco AP1250 with ACCY125X Dongle
Supply Voltage 24/48 VDC
Temperature, Operating –20 to 60 °C
Transfer Rate, Ethernet 10-100 Mbit/s
Transfer Rate, LAN 54 Mbit/s
Type Switch
Weight 0.29 kg
