2SC4656-R

2SC4656-r NPN三极管 50V 50mA 250MHz 250~500 100mV/0.1V SOT-523/SC-75 marking/标记 AMR 高频放大

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO | 50V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO | 50V 集电极连续输出电流ICCollector CurrentIC | 50mA 截止频率fTTranstion FrequencyfT | 250MHz 直流电流增益hFEDC Current GainhFE | 250~500 管压降VCE（sat）Collector-Emitter Saturation Voltage | 100mV/0.1V 耗散功率PcPower Dissipation | 125mW/0.125W Description & Applications | Features •Silicon PNP epitaxial planer type •For high-frequency amplification Complementary to 2SC4656 •High transition frequency fT. •Small collector output capacitance Cob •SS-Mini type package, allowing downsizing of the equipment and automatic insertion through the tape packing and the magazine packing. 描述与应用 | 特点 •PNP硅外延平面型 •对于高频放大互补2SC4656 •高转换频率fT。 •小集电极输出电容芯 •SS-迷你型包装，让瘦身的设备通过自动插入带包装盒包装。
