AMP FROM TE CONNECTIVITY 5-104652-2 线至板连接器, AMPMODU 50/50 Grid系列, 20 触点, 插座, 1.27 mm, 表面安装 , 2 排
**TE connectivity AMPMODU 50/50 1.27mm x 1.27mm Grid Board to Board Vertical Receptacles**
AMPMODU 50/50 1.27mm x 1.27mm grid board to board vertical receptacles for SMT parallel board to board stacking in high density .050 x .050 applications. Parallel board to board stack heights of 6.35mm, 8.13mm and 9.91mm can by achieved using the same receptacle and selecting the appropriate header board to board .050 x.050 double row vertical and right angle headers. These AMPMODU 50/50 1.27mm x 1.27mm vertical SMT board to board receptacle connectors have UL 94V-0 black glass filled thermoplastic housings, PCB hold down posts, polarizing tabs, gold plated contacts and are compatible with IR infrared and VPRvapor phase reflow surface mount processes.
触点数 20
极性 Female
触点电镀 Tin, Tin over Nickel, Gold
额定电压AC 30.0 V
额定电流 4 A
绝缘电阻 5000 MΩ
排数 2
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 20
额定电流Max 4A/触头
额定电压Max 30 VAC
额定电压 30 V
接触电阻Max 16 mΩ
安装方式 Surface Mount
引脚间距 1.27 mm
长度 17.17 mm
宽度 3.05 mm
高度 4.83 mm
引脚间距 1.27 mm
外壳颜色 Black
颜色 Black
触点材质 Copper Alloy
工作温度 -65℃ ~ 105℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Tube
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
HTS代码 8536694040
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
5-104652-2 TE Connectivity 泰科 | 当前型号 | 当前型号 |
104652-2 泰科 | 功能相似 | 5-104652-2和104652-2的区别 |
SFML-110-T2-S-D 申泰电子 | 功能相似 | 5-104652-2和SFML-110-T2-S-D的区别 |
SFM-110-02-S-D 申泰电子 | 功能相似 | 5-104652-2和SFM-110-02-S-D的区别 |
