2SD2402

2SD2402 NPN三极管 Vcbo=50V Vceo=30V Ic= 5A ft=170MHz HFE=200~400 Vce=140mV/0.14V SOT-89 marking/标记 EZ 低频功率放大器 中速切换

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO | 50V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO | 30V 集电极连续输出电流ICCollector CurrentIC | 5A 截止频率fTTranstion FrequencyfT | 170MHz 直流电流增益hFEDC Current GainhFE | 160~320 管压降VCE（sat）Collector-Emitter Saturation Voltage | 140mV/0.14V 耗散功率PcPower Dissipation | 2W Description & Applications | NPN SILICON EPITAXIAL TRANSISTOR FOR LOW-FREQUENCY POWER AMPLIFIERS AND MID-SPEED SWITCHING FEATURES • High current capacitance • Low collector saturation voltage • Complementary transistor with 2SB1571 描述与应用 | NPN硅外延晶体管低频功率放大器和中速切换 特点 •高电流电容 •低集电极饱和电压 •互补晶体管2SB1571
