100 W 单输出 3.2A 30 Vdc 输出最大值 开关电源
**Features:**
* Universal AC Input/Full Range Up to 295 VAC
* Protections: Short Circuit, Overload, Over Voltage, Over Temperature
* Cooling By Free Air Convection
* Built-In Active PFC Function
* OCP Point Adjustable Through Output Cable or Internal Potential Meter
* IP67/IP65 Design for Indoor or Outdoor Installation
* Three in One Dimming Function 1-10 VDC or PWM Signal or Resistor
* Suitable for LED Lighting and Moving Sign Applications
* Compliance with Worldwide Safety Regulations for Lighting
* 5-Year Factory Warranty
额定功率 96 W
输出接口数 1
输出电压 30 VDC
输出电流 3.2 A
通道数 1
输出功率 96 W
隔离电压 3.75 kV
输入电压Max 305 VAC
输入电压Min 90 VAC
输入电压DC Max 431 V
输入电压DC Min 127 v
输入电压AC Max 305 v
输入电压AC Min 90 v
输出电压Max 30 V
输出电压Min 15 V
输出电流Max 3200 mA
输入电流Min 1.2 A
输出功率Max 96 W
工作温度Max 90 ℃
工作温度Min -40 ℃
电源电压 90.305VAC, 127.431VDC
输入电压 100VAC ~ 305VAC
安装方式 Chassis
引脚数 5
封装 Metal Enclosure
长度 220 mm
宽度 68 mm
高度 38.8 mm
封装 Metal Enclosure
重量 1.12 kg
工作温度 -40℃ ~ 80℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409520
