NCV303LSN49T1G

电压检测器系列具有可编程延迟 Voltage Detector Series with Programmable Delay

The NCP/NCV302 and NCP/NCV303 series are second generation ultra-low current voltage detectors that contain a programmable time delay generator. These devices are specifically designed for use as reset controllers in portable microprocessor based systems where extended battery life is paramount.Each series features a highly accurate under voltage detector with hysteresis and an externally programmable time delay generator. This combination of features prevents erratic system reset operation.The NCP/NCV302 series consists of complementary output devices that are available with either an active high or active low reset. The NCP/NCV303 series has an open drain N-channel output with an active low reset output.

Features |   | Benefits

---|---|---

 | |  | |  |

.

NCV Version for Automotive

|   |

.

AEC-Q100 Qualified

.

Quiescent Current of 0.5 uA Typical

|   |

.

High Accuracy Under Voltage Threshold of 2.0%

|   |

.

Externally Programmable Time Delay Generator

|   |

.

Wide Operating Voltage Range of 0.8 V to 10 V

|   |

.

Complementary or Open Drain Output

|   |

.

Active Low or Active High Reset

|   |

.

Pb-Free Packages are Available

|   |
