HPCP410RA

HPCP410RA图片1
HPCP410RA图片2
HPCP410RA图片3
HPCP410RA图片4
HPCP410RA概述

Audio/RCA Connector, 4Poles, Solder Terminal, Plug

4 Power Position Circular Connector Receptacle, Non-Gendered Solder


得捷:
CONN CIRC RCPT 4POS SILVER SLDR


艾睿:
Are you looking for a solution to connecting a circuit to a power supply? Then use this HPCP410RA power connector from Switchcraft for a secure connection! This F connector&s;s 4power contacts that are made out of copper alloy and plated with silver. It has a female type gender. It has a maximum voltage rating of 1500 VAC. It has a right angle body orientation. This connector has a single port. HPCP410RA is housed in thermoplastic. This device has a maximum current rating of 30 A. This power connector has a minimum operating temperature of -55 °C and a maximum of 85 °C. Its 4 terminals use the solder termination method. This product is 32.9 mm deep.


HPCP410RA中文资料参数规格
技术参数

额定电流 30 A

针脚数 4

额定电流Max 30 A

工作温度Max 85 ℃

工作温度Min -55 ℃

额定电压Max 1500 VAC

封装参数

安装方式 Through Hole

物理参数

颜色 Black

触点材质 Copper Alloy

工作温度 -55℃ ~ 85℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买HPCP410RA
型号: HPCP410RA
制造商: Switchcraft / Conxall
描述:Audio/RCA Connector, 4Poles, Solder Terminal, Plug
