HTSW-102-06-G-S

SAMTEC HTSW-102-06-G-S Board-To-Board Connector, 2.54mm, 2Contacts, Header, HTSW Series, Through Hole, 1Rows

针座 通孔 2 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 2POS 2.54MM

艾睿:
Mounting this unshrouded HTSW-102-06-G-S header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 2 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a header type gender. It has a straight body orientation. This is a 1-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. This product is 5.08 mm long, 5.21 mm tall and 2.48 mm deep. It uses the solder termination method. HTSW-102-06-G-S is housed in natural liquid crystal polymer.

安富利:
Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  HTSW-102-06-G-S  Board-To-Board Connector, 2.54 mm, 2 Contacts, Header, HTSW Series, Through Hole, 1 Rows
