SAMTEC HTSW-102-23G-S Board-To-Board Connector, 2.54mm, 2Contacts, Header, HTSW Series, Through Hole, 1Rows
针座 通孔 2 位置 0.100"(2.54mm)
欧时:
HEADER VERT 2POS 2.54MM
得捷:
CONN HEADER VERT 2POS 2.54MM
艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s unshrouded HTSW-102-23-G-S header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 2 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product is 5.08 mm long, 8.38 mm tall and 2.48 mm deep. HTSW-102-23-G-S is housed in natural liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.
安富利:
Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole
Newark:
# SAMTEC HTSW-102-23-G-S Board-To-Board Connector, 2.54 mm, 2 Contacts, Header, HTSW Series, Through Hole, 1 Rows
触点数 2
极性 Male
触点电镀 Gold
排数 1
针脚数 2
额定电流Max 6.3A/触头
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压Max 550 VAC
安装方式 Through Hole
引脚间距 2.54 mm
高度 8.38 mm
引脚间距 2.54 mm
外壳颜色 Natural
触点材质 Phosphor Bronze
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Bag
制造应用 -, Industrial
RoHS标准 RoHS Compliant
含铅标准 无铅
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
HTSW-102-23-G-S Samtec 申泰电子 | 当前型号 | 当前型号 |
HTSW-102-23-L-S 申泰电子 | 完全替代 | HTSW-102-23-G-S和HTSW-102-23-L-S的区别 |
HTSW-102-23-F-S 申泰电子 | 完全替代 | HTSW-102-23-G-S和HTSW-102-23-F-S的区别 |
HTSW-102-23-LM-S 申泰电子 | 完全替代 | HTSW-102-23-G-S和HTSW-102-23-LM-S的区别 |
