HTSW-107-23-F-D

SAMTEC HTSW-107-23F-D Board-To-Board Connector, 2.54mm, 14Contacts, Header, HTSW Series, Through Hole, 2Rows

针座 通孔 14 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 14POS 2.54MM

艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded HTSW-107-23-F-D header connector from Samtec. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 6.3 A/contact. HTSW-107-23-F-D is housed in natural liquid crystal polymer. This product is 17.78 mm long, 8.38 mm tall and 5.02 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  HTSW-107-23-F-D  Board-To-Board Connector, 2.54 mm, 14 Contacts, Header, HTSW Series, Through Hole, 2 Rows
