SHT35-DIS-B2.5KS

温度与湿度传感器, 0至100％RH, -40°C至125°C, I2C, 数字, DFN-8, 2.15至5.5 V

Humidity and temperature sensor in tiny 8-pin DFN package. Its functionality includes enhanced signal processing, two distinctive and user selectable I2C addresses and communication speeds of up to 1MHz.

.

Fully calibrated, linearized, and temperature compensated digital output

.

Wide supply voltage range from 2.15V to 5.5V

.

Typical accuracy of +/-1.5 %RH and +/- 0.1°C for SHT35

.

Very fast start-up and measurement time
