2SC5026-R

2SC5026-R NPN三极管 80V 1A 120MHz 120~240 2V SOT-89/SC-62 marking/标记 2AR 低频输出放大

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO| 80V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO| 80V 集电极连续输出电流ICCollector CurrentIC| 1A 截止频率fTTranstion FrequencyfT| 120MHz 直流电流增益hFEDC Current GainhFE| 120~240 管压降VCE（sat）Collector-Emitter Saturation Voltage| 2V 耗散功率PcPower Dissipation| 1W Description & Applications| Features • Silicon NPN epitaxial planer type • For low-frequency output amplification Complementary to 2SA1890 • Low collector to emitter saturation voltage VCEsat • High collector to emitter voltage VCEO. • Mini Power type package, allowing downsizing of the equipment and automatic insertion through the tape packing and the magazine packing 描述与应用| 特点 •NPN硅外延平面型 •对于低频输出放大互补2SA1890 •低集电极到发射极饱和电压VCE（SAT） •高集电极到发射极电压VCEO。 •迷你功率型封装，允许缩减设备通过自动插入带包装盒包装
