3M N3372-6002RB Wire-To-Board Connector, 2.54mm, 60Contacts, Header, 3000 Series, Through Hole, 2Rows
™ 2 Row Header
Optional ejector latches supplied as a separate item. Durable, fully-shrouded housing protects 0.025" square pins with 30 μ" gold plating. The ejector latches provide secure retention and removal. Available right-angle and straight pin models. These headers are high temperature and RoHS compliant.
60 Position, Straight Header, Board mount
* High Temperature
* RoHS Compliant
* Surface-Mount Compatible
* Optional Ejector Latches Supplied as Separate Items
* Mounting Holes for Securing Header to Board
* 30μ" Gold Plating
触点数 60
极性 Male
触点电镀 Gold
额定电流 1.75 A
绝缘电阻 1.00 GΩ
排数 2
易燃性等级 UL 94 V-0
针脚数 60
安装方式 Through Hole
引脚间距 2.54 mm
长度 95.6 mm
宽度 8.30 mm
高度 17.3 mm
引脚间距 2.54 mm
外壳颜色 Black
颜色 Black
触点材质 Copper Alloy
工作温度 -55℃ ~ 105℃
外壳材质 Polyester
产品生命周期 Active
包装方式 Bulk
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
N3372-6002RB 3M | 当前型号 | 当前型号 |
N3372-620T02RB 3M | 完全替代 | N3372-6002RB和N3372-620T02RB的区别 |
N3372-600T02RB 3M | 完全替代 | N3372-6002RB和N3372-600T02RB的区别 |
3372-600T02TC 3M | 完全替代 | N3372-6002RB和3372-600T02TC的区别 |
