FAIRCHILD SEMICONDUCTOR 74LCX32MX 或门, 2输入, 4门, 2V至3.6V, NSOIC-14
Dump the microprocessor and build your circuit using fundamental logical operations using Semiconductor"s logic gates. This gate has a minimum operating temperature of -40 °C and a maximum of 85 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 2 V, while its maximum is 3.6 V.
电源电压DC 2.50 V
输出接口数 1
电路数 4
针脚数 14
逻辑门个数 4
输入数 2
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
长度 8.75 mm
宽度 4 mm
高度 1.5 mm
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
74LCX32MX Fairchild 飞兆/仙童 | 当前型号 | 当前型号 |
74LCX32M 飞兆/仙童 | 完全替代 | 74LCX32MX和74LCX32M的区别 |
SN74LVC32ADR 德州仪器 | 功能相似 | 74LCX32MX和SN74LVC32ADR的区别 |
SN74LVC32AD 德州仪器 | 功能相似 | 74LCX32MX和SN74LVC32AD的区别 |
