0.5mm DOUBLE ROW MI SOCKET ASSEMBLY
120 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold
欧时:
CONN RCPT 120POS SMD GOLD
得捷:
CONN RCPT 120POS SMD GOLD
立创商城:
QSH-060-01-H-D-A-K-TR
艾睿:
Use this micro high speed socket strip QSH-060-01-H-D-A-K-TR connector from Samtec when board-to-board interconnects is required. This SKT connector&s;s 120 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a socket type gender. It has a maximum voltage rating of 125 VAC. This is a 2-row connector. Its pitch is 0.5 mm. This device has a maximum current rating of 2/25 A/contact. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 41.27 mm long, 3.25 mm tall and 7.49 mm deep. QSH-060-01-H-D-A-K-TR is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.
Newark:
# SAMTEC QSH-060-01-H-D-A-K-TR .5mm DOUBLE ROW MI SOCKET ASSEMBLY
Win Source:
CONN RCPT 120POS SMD GOLD / 120 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold
