Conn Socket Strip SKT 10POS 2.54mm Solder RA SMD Tube
10 Position Receptacle Connector Surface Mount, Right Angle
得捷:
CONN RCPT 10POS 0.1 GOLD SMD R/A
艾睿:
Look no further than the socket strip SSM-105-L-DH-LC header connector from Samtec, a great tool to use when board-to-board interconnects is required. This SKT connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. Its pitch is 2.54 mm. It has a right angle body orientation. It has a maximum voltage rating of 510 VDC|360VAC. It has a socket type gender. This device has a maximum current rating of 5.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 12.7 mm long, 5.72 mm tall and 11.18 mm deep. SSM-105-L-DH-LC is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.
安富利:
Conn Socket Strip SKT 10 POS 2.54mm Solder RA SMD Tube
