Voltage Rating 465VAC, 655VDC
Insulation Material Liquid Crystal Polymer LCP
Contact Shape Square
Contact Material Phosphor Bronze
Contact Finish Thickness - Post 3.00µin 0.076µm
Base Product Number SSQ-125
Standard Package 1
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1290828-SSQ-125-01-G-D-LL
Fake Threat In the Open Market 53 pct.
Contact Finish - Post Gold
Material Flammability Rating UL94 V-0
Temperature Range - Operating -55°C ~ 125°C
Contact Length - Post 0.104" 2.64mm
Insulation Height 0.335" 8.51mm
Insulation Color Black
Contact Finish Thickness - Mating 20.0µin 0.51µm
Contact Finish - Mating Gold
Fastening Type Push-Pull
Termination Press-Fit, Solder
Mounting Type Through Hole
Row Spacing - Mating 0.100" 2.54mm
Number of Rows 2
Pitch - Mating 0.100" 2.54mm
Number of Positions Loaded All
Number of Positions 50
Style Board to Board or Cable
Contact Type Forked
Connector Type Receptacle
Package Bulk
Series SSQ
Mfr Samtec Inc.
Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
RoHS标准 RoHS Compliant
