TSW-113-08-F-D-RA

SAMTEC TSW-113-08-F-D-RA Board-To-Board Connector, 2.54mm, 26Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔，直角 26 位置 0.100"（2.54mm）

欧时:
Classic PCB HDR Strips 0.100"

得捷:
CONN HEADER R/A 26POS 2.54MM

艾睿:
Use this unshrouded TSW-113-08-F-D-RA connector from Samtec when board-to-board interconnects is required. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a header type gender. It has a right angle body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 450 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 33.02 mm long, 5.56 mm tall and 12.44 mm deep. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-113-08-F-D-RA is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder RA Thru-Hole

Newark:
# SAMTEC  TSW-113-08-F-D-RA  Board-To-Board Connector, 2.54 mm, 26 Contacts, Header, TSW Series, Through Hole, 2 Rows
