信号调节
频率范围Frequency Range| 2.4GHz - 2.5GHz \---|--- 阻抗 - 非平衡/平衡Impedance - Unbalanced/Balanced| 50/50 Ω 相位差Phase Difference| 180°±10 插入损耗（最大值）Insertion Loss Max| 1.2dB 回波损耗（最小值）Return Loss Min| 10dB Description & Applications| XFRMR BALUN RF 2.4GHZ SMD 描述与应用| XFRMR BALUN RF 2.4GHZ SMD
得捷:
BALUN 2.4GHZ-2.5GHZ 50/50 0805
立创商城:
HHM1517
艾睿:
Are your designing a communication system? Implement this HHM1517 telecom transformer manufactured by TDK, for the fastest speeds. This telecom transformer has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 6 terminals. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 2 mm long, 0.95 mm tall and 1.25 mm deep. It also has a w-lan transformer.
安富利:
Multilayer Chip Balun 6-Pin SMD Blister T/R
Chip1Stop:
Telecom Transformer 1.2dB Surface Mount
Verical:
Multilayer Balun Transformers HHM Series
DeviceMart:
XFRMR BALUN RF 2.4GHZ SMD
Win Source:
RF Balun 2.4GHz ~ 2.5GHz 50 / 50 Ohm 0805 2012 Metric
