可配置电压转换和三态输出的双位双电源总线收发器 DUAL-BIT DUAL-SUPPLY BUS TRANSCEIVER WITH CONFIGURABLE VOLTAGE TRANSLATION AND 3-STATE OUTPUTS
电压电平 转换器 双向 1 电路 2 通道 500Mbps 8-VSSOP
立创商城:
CAVC2T45TDCURQ1
得捷:
IC TRNSLTR BIDIRECTIONAL US8
贸泽:
Translation - Voltage Levels AC DualB Dual-Supply Bus Xcvr
艾睿:
Are you looking for a device that can regulate the input voltage into your circuit? Texas Instruments&s; CAVC2T45TDCURQ1 level translator is the perfect solution for you. This level shifter has a minimum operating temperature of -40 °C and a maximum of 105 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.2 V, while its maximum is 3.6 V.
安富利:
Voltage Level Translator 8-Pin VSSOP T/R
Chip1Stop:
Voltage Level Translator Automotive 8-Pin VSSOP T/R
Verical:
Voltage Level Translator 2-CH Bidirectional Automotive 8-Pin VSSOP T/R
DeviceMart:
IC BUS TXRX 3-ST DUAL US8
Win Source:
IC BUS TXRX 3-ST DUAL US8
德州仪器TI:
Automotive Dual-Bit Dual-Supply Bus Transceiver with Config Voltage Translation and 3-State
电源电压DC 1.20V ~ 3.60V
电路数 1
通道数 2
位数 2
传送延迟时间 2.40 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
输出通道数 1
电源电压 1.2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 1.2 V
安装方式 Surface Mount
引脚数 8
封装 VSSOP-8
封装 VSSOP-8
工作温度 -40℃ ~ 105℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
