4612X-101-222LF

Res Thick Film NET 2.2KΩ 2% 1.5W ±100ppm/℃ BUS Conformal 12Pin SIP Pin Thru-Hole Bulk

2.2k 欧姆 ±2% 200mW 每元件功率 总线式 器网络，阵列 ±100ppm/°C 12-SIP

得捷:
RES ARRAY 11 RES 2.2K OHM 12SIP

立创商城:
2.2kΩ ±2%

艾睿:
By combining multiple resistors into a single chip, the 4612X-101-222LF resistor array, developed by Bourns, can help you save space and power in your circuit design. This dependable part has a power rating of 1.5 W and a power rating per resistor of 0.2 1/5 W. This product&s;s 11 resistors have a value of 2.2K Ohm. Its temperature coefficient is ±100 ppm/°C. It has 12 terminals. This product comes packaged in bulk, so the parts will be stored loosely. It has a tolerance of 2%. The 4612X-101-222LF part has a pin termination style. This part has an operating temperature of -55 to 125 °C. This product&s;s terminal pitch is 2.54 mm. This device utilizes thick film technology. This product is 30.43 mm long, 5.08 mm tall and 2.49 mm deep.

安富利:
Res Thick Film NET 2.2K Ohm 2% 1.5W ±100ppm/°C BUS Conformal 12-Pin SIP Pin Thru-Hole Bulk

Chip1Stop:
Res Thick Film NET 2.2K Ohm 2% 1.5W ±100ppm/℃ BUS Conformal Coated 12-Pin SIP Pin Thru-Hole Bulk

Electro Sonic:
Res Thick Film NET 2.2K Ohm 2% 1.5W ±100ppm/°C BUS Conformal Coated 12-Pin SIP Pin Thru-Hole Bulk
