H859RBYA

51.1Ω to 976ΩAxial Leaded Precision HOLCO Series resistors have Ultra Precision – down to 0.05% High Pulse Withstand Low Reactance Low TCR- down to 5ppm/°C Long term stability Up to 1 Watt at 70°C Matched sets available to 2ppm/°C ### Metal Film,HOLCO Axial ±0.1% 0.25W70°C 时功率 | 0.25W ---|--- 电阻容差 | ±0.1% 温度系数 | ±15ppm/°C 极限元件电压 | 200V 直流或交流有效值 工作温度 | \- 55°C → +155°C 尺寸 mm --- 主体长度 | 7.2 主体直径 | 2.5 引线长度 | 30 引线直径 | 0.6

51.1Ω 至 976Ω

轴向引线式精密 HOLCO 系列器具有超高精度 - 低至 0.05%

高脉冲耐受

低电抗

低 TCR - 低至 5ppm/°C

长期稳定性

70°C 时高达 1W

匹配套件可提供 2ppm/°C

### 金属膜，HOLCO 轴向 ±0.1% 0.25W

得捷:
RES 59 OHM 0.1% 1/4W AXIAL

立创商城:
59Ω ±0.1% 250mW

Allied Electronics:
HOLCO Series Axial Metal Film Resistor 59Ohms +/-0.1% 0.25W +/-15ppm/degC

安富利:
Res Metal Film 59 Ohm 0.1% 1/4W ±15ppm/°C Conformal AXL Thru-Hole Bandoliered

Chip1Stop:
Res Metal Film 59 Ohm 0.1% 0.25W1/4W ﾂｱ15ppm/C Conformal Coated AXL Bandoliered
