XCSDMC590L01M8

型号： XCSDMC590L01M8

制造商： Telemecanique

描述：XPS-DM 和 XCS-DM 带编码的磁性开关和控制器 带编码的 XCS-DM 舌簧开关，额定值为 24V 直流、100mA，与 XPS-DM 安全继电器配合使用时可提供经认证的防护监控安全解决方案 XPS-DM Preventa 安全继电器可执行多开关监控并达到符合 EN954-1 标准的 4 类安全解决方案的要求 3 面操动：面对面和面对侧 未对准的最大间隙为 6mm LED 型在产品中采用了具有一个常闭触点的 LED，防护关闭时该 LED 会亮起 带编码的舌簧技术。 只用磁铁不能够使开关完全瘫痪 尺寸：小型：H51 x W16 x D7 mm，标准：H88 x W25 x D13 mm，安全模块：H99 x W22 x D114 mm The Schneider XCS-DM coded magnetic safety switches are designed for monitoring the doors, covers and guards of industrial machines with imprecise guiding and low inertia. These safety switches are ideally suited for machines subjected to frequent washing or liquid spray. They protect the operator by immediately stopping any dangerous movement as soon as the distance between the switch and its magnet is greater than 8mm 5mm for XCS-DMC. The Schneider XPS-DM safety modules are specifically designed for monitoring the coded magnetic safety switches. When the XCS-DM safety switch is used in conjunction with the XPS-DM safety relay they offer a certified safety solution
