N沟道,30V,150A,2.4mΩ@4.5V
二极管与整流器
得捷:
MOSFET N-CH 30V 54A/150A 8DFN
立创商城:
N沟道 30V 54A
艾睿:
Thanks to Alpha &a; Omega Semiconductor, both your amplification and switching needs can be taken care of with one component: the AON6512 power MOSFET. Its maximum power dissipation is 83000 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This MOSFET transistor has an operating temperature range of -55 °C to 150 °C. This N channel MOSFET transistor operates in enhancement mode.
Chip1Stop:
Trans MOSFET N-CH 30V 85A 8-Pin DFN EP T/R
Verical:
Trans MOSFET N-CH 30V 54A 8-Pin DFN EP T/R
Win Source:
MOSFET N-CH 30V 54A 8DFN
极性 N-CH
耗散功率 83 W
漏源极电压Vds 30 V
连续漏极电流Ids 85A
上升时间 5 ns
输入电容Ciss 3430pF @15VVds
额定功率Max 83 W
下降时间 9.8 ns
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 7.4W Ta, 83W Tc
安装方式 Surface Mount
引脚数 8
封装 DFN-8
封装 DFN-8
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
香港进出口证 NLR
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
AON6512 Alpha & Omega Semiconductor 万代半导体 | 当前型号 | 当前型号 |
AON6702 万代半导体 | 类似代替 | AON6512和AON6702的区别 |
