ANALOG DEVICES ADG888YRUZ 模拟开关, 双通道, DPDT, 2 放大器, 0.4 ohm, 4.2V 至 5.5V, TSSOP, 16 引脚
单电源 2V 至 16V 开关和多路复用器,Analog Devices
低接通电阻
低失真
闩锁抗扰性
高 ESD 等级
### 开关和多路复用器,Analog Devices
得捷:
IC SWITCH DUAL DP4T 16TSSOP
欧时:
ADG888YRUZ,
立创商城:
ADG888YRUZ
贸泽:
模拟开关 IC 400mOhm 5.5V CMOS Dual DPDT
e络盟:
模拟开关, 双通道, 2 放大器, DPDT, 0.4 ohm, 4.2V 至 5.5V, TSSOP, 16 引脚
艾睿:
Analog Switch Dual DPDT Automotive 16-Pin TSSOP Tube
安富利:
The ADG888 is a low voltage, dual DPDT double-pole, double-throw CMOS device optimized for high performance audio switching. With its low power and small physical size, it is ideal for portable devices.This device offers ultralow on resistance of less than 0.8 Ω over the full temperature range, making it an ideal solution for applications requiring minimal distortion through the switch. The ADG888 also has the capability of carrying large amounts of current, typically 400 mA at 5 V operation.When on, each switch conducts equally well in both directions and has an input signal range that extends to the supplies. The ADG888 exhibits break-before-make switching action.
Chip1Stop:
Analog Switch Dual DPDT Automotive 16-Pin TSSOP Tube
TME:
IC: analog switch; DPDT; Channels:2; TSSOP16; 1.8÷5.5VDC
Verical:
Analog Switch Dual DPDT Automotive 16-Pin TSSOP Tube
Newark:
Analog Switch, Dual Channel, DPDT, 2 Channels, 0.4 ohm, 1.8V to 5.5V, TSSOP, 16 Pins
输出接口数 8
触点类型 DPDT
供电电流 3 nA
电路数 2
通道数 2
针脚数 16
位数 2
耗散功率 20.0 µW
带宽 29.0 MHz
输入数 4
工作温度Max 125 ℃
工作温度Min -40 ℃
3dB带宽 29 MHz
电源电压 4.2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
长度 5.1 mm
宽度 4.4 mm
高度 1.2 mm
封装 TSSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
制造应用 Portable , Audio, 多媒体, Computers & Computer Peripherals, 成像, 视频和目视, Consumer Electronics, 便携式器材, Communications & Networking, 音频, 通信与网络, Imaging, Video & Vision, 电源管理, 视频和目视, Multimedia, Portable Devices, Communications & N, 计算机和计算机周边, Power Management
RoHS标准 RoHS Compliant
含铅标准 PB free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADG888YRUZ ADI 亚德诺 | 当前型号 | 当前型号 |
ADG888YRUZ-REEL7 亚德诺 | 完全替代 | ADG888YRUZ和ADG888YRUZ-REEL7的区别 |
ADG888YRUZ-REEL 亚德诺 | 完全替代 | ADG888YRUZ和ADG888YRUZ-REEL的区别 |
ADG888YCPZ-REEL 亚德诺 | 完全替代 | ADG888YRUZ和ADG888YCPZ-REEL的区别 |
