参考电压,2.5V,Analog Devices### 电压参考,Analog Devices精密固定和可调电压参考 IC 利用串联、并联或串联/并联拓扑,并提供通孔和表面安装封装。 电压参考的初始准确度为 ±0.02 至 ±2%。
参考电压,2.5V,Analog Devices
### 电压参考,Analog Devices
精密固定和可调电压参考 IC 利用串联、并联或串联/并联拓扑,并提供通孔和表面安装封装。 电压参考的初始准确度为 ±0.02 至 ±2%。
得捷:
IC VREF SERIES 0.2% 8SOIC
立创商城:
串联 10mA
欧时:
### 参考电压,2.5V,Analog Devices### 电压参考,Analog Devices精密固定和可调电压参考 IC 利用串联、并联或串联/并联拓扑,并提供通孔和表面安装封装。 电压参考的初始准确度为 ±0.02 至 ±2%。
贸泽:
参考电压 2.5V PrecisionBandgap REF
艾睿:
Even in the event of large power supply variations, this ADR03ARZ-REEL7 voltage reference power management device from Analog Devices can produce and maintain a precise DC voltage. With an output that has a voltage of 2.5 V, this is power management at its best. This will operate at a maximum voltage of 36 V, making it easy to control the power in your circuit. It has an initial accuracy of 0.2%. Using a load regulation of 70ppm/mA and line regulation of 30ppm/V is needed for a programmable DC power supply. This voltage reference circuit supports series topology. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This voltage reference circuit has an operating temperature range of -40 °C to 125 °C. It runs with a maximum temperature coefficient of 10ppm/°C.
安富利:
V-Ref Precision 2.5V 10mA 8-Pin SOIC N T/R
Chip1Stop:
V-Ref Precision 2.5V 10mA 8-Pin SOIC N T/R
Verical:
V-Ref Precision 2.5V 10mA 8-Pin SOIC N T/R
Win Source:
Series Voltage Reference IC ±0.2% 10mA 8-SOIC 0.154", 3.90mm Width
容差 ±0.2 %
输入电压DC 40.0V max
输出电压 2.5 V
输出电流 10 mA
供电电流 1 mA
通道数 1
输入电压Max 36 V
输出电压Max 2.505 V
输出电压Min 2.5 V
输出电流Max 10 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±0.2 %
输入电压 4.5V ~ 36V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 125℃ TA
温度系数 ±10 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADR03ARZ-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADR03AR-REEL7 亚德诺 | 完全替代 | ADR03ARZ-REEL7和ADR03AR-REEL7的区别 |
ADR03ARZ 亚德诺 | 类似代替 | ADR03ARZ-REEL7和ADR03ARZ的区别 |
ADR03AR 亚德诺 | 类似代替 | ADR03ARZ-REEL7和ADR03AR的区别 |
