AQV212S

PANASONIC ELECTRIC WORKS  AQV212S  继电器, MOSFET, 60 V, 500 mA, 2.5R, SPST常开

光电 PhotoMOS 继电器，带有表面安装外壳 MOSFET 输出级。

应用：电话和测量设备、高速通信系统和工业机器人。

Technical specifications

---

Configuration of contacts: | 1 N/O

**Common input characteristics:** |

Operating current: | 0.7 mA

LED off current: | 0.65 mA

LED direct current: | 50mA

LED nominal voltage: | 1.14 V

LED reverse voltage: | 3 V

Peak current: | 1A

Rated dissipation: | 75 mW

**Common output characteristics:** |

Voltage: | 60 Vac / dc

Current | 350 mA

Power: | 500 mW

Response time ton / toff: | 0.5 / 0.05 ms

Input/output capacity: | 0.8 pF

Input / output insulation resistance: | 1000MΩ

Input / output insulation: | 1500 Vac

Thermal EMF: | 1 μV

Operating temperature: | –20°C to +80°C

### 认可

  UL, CSA, TÜV
