ALZ12B12T

PANASONIC ELECTRIC WORKS  ALZ12B12T  通用继电器, LZALZ系列, 功率, 无锁定, SPDT, 12 VDC, 16 A

The LZALZ series 1a/1c 16A Power Relay with low profile. The superior insulation characteristics have been achieved by maintaining an insulation distance between coil and contacts of at least 10mm for both creepage distance and clearances. Furthermore, anti-surge voltage is 10kV and higher. It can be used in ambient temperatures up to 85°C for the class-B and 105°C for the class-F.

.

High insulation resistance

.

Superior heat resistance

.

Low operating power

.

Conforms to the various safety standards

.

Superior heat resistance and tracking resistance
