2.1 Ω导通电阻， ±15 V / + 12 V / ± 5 V的iCMOS单刀双掷开关 2.1 Ω On Resistance, ±15 V/+12 V/±5 V iCMOS SPDT Switch
GENERAL DESCRIPTION
The is a monolithic iCMOS® device containing a single-pole/double-throw SPDT switch. An EN input on the LFCSP package is used to enable or disable the device. When disabled, all channels are switched off.
FEATURES
2.1 Ω on resistance
0.5 Ω maximum on resistance flatness at 25°C
Up to 390 mA continuous current
Fully specified at +12 V, ±15 V, ±5 V
No VLsupply required
3 V logic-compatible inputs
Rail-to-rail operation
8-lead MSOP and 8-lead 3 mm × 2 mm LFCSP packages
APPLICATIONS
Automatic test equipment
Data acquisition systems
Battery-powered systems
Relay replacements
Sample-and-hold systems
Audio signal routing
Video signal routing
Communication systems
