PXA 系列 Ø 8 x 6.7 mm 6.3 V 220 uF 导电性高分子 铝 电容
Using United Chemi-con"s conductive polymer aluminum solid capacitor, easily take care of varying levels of voltage entering your circuit. It can withstand a voltage of 6.3 VDC. It has 2 terminals. It has a tolerance of 20%. Its leakage current is 277@2Min μA. This product is 6.7 mm tall with a diameter of 8 mm. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C.
额定电压DC 6.30 V
电容 220 µF
等效串联电阻ESR 25.0 mΩ
容差 ±20 %
纹波电流 3020 mA
纹波电流低频 3.02A @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Surface Mount
封装 SMD
长度 6.70 mm
宽度 8.30 mm
高度 6.7 mm
直径 8.00 mm
封装 SMD
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
寿命(小时) 2000 h
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
HTS代码 8532220020
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
APXA6R3ARA221MH70G Chemi-Con 贵弥功 | 当前型号 | 当前型号 |
APXA4R0ARA221MH70G 贵弥功 | 功能相似 | APXA6R3ARA221MH70G和APXA4R0ARA221MH70G的区别 |
EEF-WA0J221P 松下 | 功能相似 | APXA6R3ARA221MH70G和EEF-WA0J221P的区别 |
