AP139-18WG-7

DIODES INC.  AP139-18WG-7  固定电压稳压器, LDO, 2.7V至5.5V, 450mV压差, 1.8V输出, 300mA输出, SOT-25-5

The is a 1.8V fixed output low-noise low-dropout LDO Linear Regulator utilizing CMOS technology. The features that include low quiescent current 45µA typical, low dropout voltage and high output voltage accuracy, make it ideal for battery applications. EN input connected to the device will produce a low bias current. This rugged device has both thermal shutdown and current limit protections to prevent device failure under the "worst" operating conditions. In a low noise, regulated supply application, a 10nF capacitor is necessary to be placed in between Bypass and Ground. The device is stable with a low ESR output capacitor of 1µF or greater.

.

45µA Typical low current consumption

.

60uA Maximum low current consumption

.

Low temperature coefficient
