APX803 系列 4 V 140 ms 3-引脚 微处理器 复位电路 - SOT-23-3
监控器 开路漏极或开路集电极 通道 SOT-23-3
得捷:
IC SUPERVISOR 1 CHANNEL SOT23-3
立创商城:
APX803-40SAG-7
艾睿:
Your circuit won&s;t fail if its main processor goes out thanks to this APX803-40SAG-7 microprocessor supervisory circuit from Diodes Zetex. This device has a maximum power dissipation of 400 mW. Its maximum power dissipation is 400 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This part has an operating temperature range of -40 °C to 85 °C. This device has a minimum operating supply voltage of 1.1 V and a maximum of 5.5 V. It has a typical reset threshold voltage of 4 V, with a minimum of 3.94 V and a maximum of 4.06 V.
安富利:
Processor Supervisor 4V 2.5V/3V/3.3V/5V 3-Pin SOT-23 T/R
Chip1Stop:
Processor Supervisor 4V 2.5V/3V/3.3V/5V 3-Pin SOT-23 T/R
Verical:
Processor Supervisor 4V 1 Active Low/Open Drain 3-Pin SOT-23 T/R
DeviceMart:
IC MPU RESET CIRC 4.00V SOT23-3
Win Source:
IC MPU RESET CIRC 4.00V SOT23-3
耗散功率 0.4 W
阈值电压 4 V
复位电压Min 3.94 V
复位电压Max 4.06 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 400 mW
电源电压Max 5.5 V
电源电压Min 1.1 V
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
封装 SOT-23-3
工作温度 -40℃ ~ 85℃
产品生命周期 Not Recommended
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
