BR-2032/GUN概述
纽扣电池 3V 190mAH PC PINS
The is a 2032 3V/190mAh Non-rechargeable Battery, lithium polycarbon monofluoride technology with PCB-pin terminals, high voltage of 3V - twice that of conventional dry batteries, extremely small self-discharge for long service and shelf life, compact and lightweight, extremely high energy density, very safe poly-carbonmonofluoride lithium, extremely strong load pulse characteristics.
- .
- 0.03mA Continuous standard load
- .
- -30 to 80°C Operating temperature range
BR-2032/GUN中文资料参数规格
技术参数
输出电压 3 V
工作温度Max 80 ℃
工作温度Min -30 ℃
封装参数
引脚数 2
外形尺寸
高度 3.2 mm
物理参数
重量 2.5 g
工作温度 -30℃ ~ 80℃
其他
产品生命周期 Unknown
包装方式 Bulk
制造应用 Power Management, Test & Measurement, Consumer Electronics, Portable Devices, Clock & Timing
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
海关信息
ECCN代码 EAR99
