TAIYO YUDEN BRL2012T2R2M 电感, 2.2uH, 550MA, 20%, 200MHZ, SMD
无屏蔽 绕线 器 390 毫欧最大 0805(2012 公制)
得捷:
FIXED IND 2.2UH 550MA 390MOHM SM
立创商城:
2.2uH ±20% 550mA 300mΩ
贸泽:
Fixed Inductors 0805 2.2uH 390mOhms +/-20% 550mA LwPrfl
e络盟:
电感, 2.2uH, 550MA, 20%, 200MHZ, SMD
艾睿:
Inductor Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 550mA 390mOhm DCR 0805 T/R
Chip1Stop:
Inductor Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 550mA 390mOhm DCR 0805 T/R
Verical:
Inductor Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 0.55A 0.39Ohm DCR 0805 T/R
Newark:
# TAIYO YUDEN BRL2012T2R2M Surface Mount High Frequency Inductor, BR Series, 2.2 µH, 550 mA, 0805 [2012 Metric], Wirewound
Electro Sonic:
Inductor Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 0.55A 0.39Ohm DCR 0805 T/R
Win Source:
2.2μH Unshielded Wirewound Inductor 550mA 390 mOhm Max 0805 2012 Metric
额定电流 550 mA
容差 ±20 %
无卤素状态 Halogen Free
电感 2.2 µH
自谐频率 200 MHz
产品系列 BR
电感公差 ±20 %
测试频率 7.96 MHz
电阻DC) ≤390 mΩ
额定电流DC 550 mA
工作温度Max 105 ℃
工作温度Min -40 ℃
电阻DC Max 0.3 Ω
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 1 mm
封装公制 2012
封装 0805
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 3000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
