MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15A 125/250VAC, ENEC 16A 250VAC, 11,9mm [0.47in] Threaded Bushing with 8,3mm [0.326in] Diameter Hardened Steel Additional Overtravel Plunger, Solder Termination, Mounting Holes will Accept Pins or Screws, Bushing Hardware Furnished Unassembled, UL, CE, CSA, ENEC
BZ Series Standard Basic Switch, Single Pole Double Throw Circuitry, 15 A at 250 Vac, Roller Plunger Actuator, 9 oz - 13 oz Operating Force, Silver Contacts, Screw Termination, CE, CSA, DEMKO
贸泽:
Basic / Snap Action Switches 15A @ 250 VAC Plunger SPDT Screw
e络盟:
HONEYWELL BZ-2RQ785 微动开关, BZ系列, SPDT, 拧紧, 15 A, 250 VAC, 250 VDC
艾睿:
The BZ-2RQ785 snap-action switch from Honeywell makes opening or closing your circuit a fast operation. This device has a maximum current rating of 16 A @ 250VAC. It has a SPDT configuration. This snap action switch has a minimum operating temperature of -55 °C and a maximum of 85 °C. The BZ-2RQ785 snap action switch has a screw termination style. This product is 49.28 mm long, 59.13 mm tall and 17.45 mm deep. The maximum AC voltage rating is 600 VAC and the maximum DC voltage rating is 250 VDC.
Allied Electronics:
Standard Switch, Basic, SPDT, 15 Amps, 9-13 OPERATING FORCE
Chip1Stop:
Switch Snap Action N.O./N.C. SPDT Roller Plunger Screw 16A 600VAC 250VDC 186.42VA 3.61N Panel Mount
Verical:
Switch Snap Action N.O./N.C. SPDT Roller Plunger 16A 600VAC 250VDC 186.42VA 3.61N Panel Mount Screw Automotive
Newark:
# HONEYWELL BZ-2RQ785 Microswitch, BZ Series, SPDT, Screw, 15 A, 250 VAC, 250 VDC
MASTER:
MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15 A 125/250 Vac, ENEC 16 A 250 Vac, 12,7 mm [0.50 in] Threaded Bushing with Sintered Roller Plunger Actuator Rotated 90° to Major Axis, Binding Head Combination Screw
Online Components:
MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15 A 125/250 Vac, ENEC 16 A ...
GOPHER:
Basic Snap-action Switch SPDT 15 AMP SCREW TERMINAL SIDE MOUNT SILVER CONTACTS,OVERTRAVEL PLUNGER MICRO SWITCH
Electro Sonic:
MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15 A 125/250 Vac, ENEC 16 A ...
Win Source:
SWITCH SNAP ACTION SPDT 15A 125V / Switch SPDT Panel Mount
额定电压DC 250 V
额定电压AC 600 V
额定电流 15 A
触点类型 SPDT
触点额定电流 15.0 A
额定电流Max 16A @250VAC
额定功率Max 186.42 VA
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 250 VAC
额定电压DC Max 250 V
额定电压AC Max 600 V
安装方式 Screw Terminals
宽度 49.3 mm
高度 59.13 mm
触点材质 Silver
材质 Plastic
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
HTS代码 8536509055
