BGA725L6E6327FTSA1

BGA725L6 1.5 至 3.6 V 0.65 dB 表面贴装 前端 低噪声 放大器 - TSLP-6-2

Description:

The BGA725L6 is a front-end low noise amplifier for Global Navigation Satellite Systems GNSS from 1550 MHz to 1615 MHz like GPS, GLONASS, Beidou, Galileo and others. The LNA provides 20.0 dB gain and 0.65 dB noise figure at a current consumption of 3.6 mA in the application configuration described. The BGA725L6 is based upon Technologies‘ B7HF Silicon Germanium technology. It operates from 1.5 V to 3.6 V supply voltage.

Summary of Features:

.

High insertion power gain: 20.0 dB

.

Out-of-band input 3rd order intercept point: -2 dBm

.

Input 1 dB compression point: -15 dBm

.

Low noise figure: 0.65 dB

.

Low current consumption: 3.6 mA

.

Operating frequencies: 1550 - 1615 MHz

.

Supply voltage: 1.5 V to 3.6 V

.

Digital on/off switch 1V logic high level

.

Ultra small TSLP-6-2 leadless package footprint: 0.7 x 1.1 mm2

.

B7HF Silicon Germanium technology

.

RF output internally matched to 50 Ω

.

Only 1 external SMD component necessary

.

2kV HBM ESD protection including AI-pin

.

Pb-free RoHS compliant package
