Mini-MELF 9.1V 0.5W1/2W
- 齐纳 ±6% 表面贴装型 迷你型 MELF
得捷:
DIODE ZENER 9.1V 500MW MINI MELF
艾睿:
Check out this perfect BZV55C9V1-TP zener diode from Micro Commercial Components for operating in the reverse breakdown region. Its maximum leakage current is 0.1 μA. Its test current is 5 mA. Its maximum power dissipation is 500 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This zener diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. It is made in a single configuration. This zener device has a nominal voltage of 9.1 V and a voltage tolerance of 6%.
Chip1Stop:
Diode Zener Single 9.1V 6% 500mW 2-Pin Mini-MELF T/R
Verical:
Zener Diode Single 9.1V 6% 10Ohm 500mW 2-Pin Mini-MELF T/R
Win Source:
DIODE ZENER 9.1V 500MW MINIMELF
