VISHAY BAW27-TAP 二极管 小信号, 单, 75 V, 300 mA, 1.25 V, 6 ns, 4 A
The is a silicon epitaxial planar Small Signal Switching Diode features low forward voltage drop and high forward current capability. It is used in high speed switching and general purpose use in computer and industrial applications.
额定电流 200 mA
针脚数 2
正向电压 1.25 V
反向恢复时间 6 ns
正向电流 300 mA
最大正向浪涌电流(Ifsm) 4 A
正向电压Max 1.25 V
工作温度Max 175 ℃
工作温度Min 65 ℃
工作结温 175℃ Max
安装方式 Through Hole
引脚数 2
封装 DO-35-2
长度 3.9 mm
宽度 1.7 mm
高度 1.7 mm
封装 DO-35-2
工作温度 -65℃ ~ 175℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Computers & Computer Peripherals, Industrial
RoHS标准 RoHS Compliant
含铅标准 无铅
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BAW27-TAP Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
BAW62 恩智浦 | 功能相似 | BAW27-TAP和BAW62的区别 |
