Vishay Semiconductor肖特基整流器是半导体二极管,具有极低的正向电压降和非常快的切换作用。 肖特基二极管的反向恢复时间非常快。 肖特基二极管适用于需要快速切换和低功耗的应用。### 肖特基整流器,Vishay Semiconductor
The is a Small Signal Schottky Diode with integrated protection ring against static discharge. It is used as general purpose and switching Schottky barrier diode. It can also be used in HF-detector, protection circuit, diode for low currents with a low supply voltage, small battery charger, power supplies and DC/DC converter for notebooks.
额定电流 30.0 mA
电容 1.60 pF
针脚数 2
正向电压 1V @15mA
正向电流 30 mA
最大正向浪涌电流(Ifsm) 500 mA
正向电压Max 1 V
正向电流Max 30 mA
工作温度Max 150 ℃
工作温度Min 65 ℃
工作结温 125℃ Max
安装方式 Surface Mount
引脚数 2
封装 SMD-2
长度 2 mm
宽度 1.2 mm
高度 1.2 mm
封装 SMD-2
工作温度 125 ℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Power Management, 车用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BAS381-TR3 Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
BAS381-TR 威世 | 类似代替 | BAS381-TR3和BAS381-TR的区别 |
1PS76SB70 恩智浦 | 功能相似 | BAS381-TR3和1PS76SB70的区别 |
