BDX53B

STMICROELECTRONICS  BDX53B  单晶体管 双极, 达林顿, NPN, 80 V, 60 W, 8 A, 750 hFE

NPN 复合，STMicroelectronics

欧时:
NPN 复合晶体管，STMicroelectronics### 双极晶体管，STMicroelectronicsSTMicroelectronics 的各种 NPN 和 PNP 双极性晶体管，包括通用、达林顿、功率和高电压设备，采用表面安装和通孔封装。

得捷:
TRANS NPN DARL 80V 8A TO220

立创商城:
BDX53B

艾睿:
Increase the current gain in your circuit by using STMicroelectronics&s; NPN BDX53B Darlington transistor. This product&s;s maximum continuous DC collector current is 8 A, while its minimum DC current gain is 750@3A@3 V. It has a maximum collector emitter saturation voltage of 2@12mA@3A V. This Darlington transistor array&s;s maximum emitter base voltage is 5 V, while its maximum base emitter saturation voltage is 2.5@12mA@3A V. Its maximum power dissipation is 60000 mW. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It has a maximum collector emitter voltage of 80 V and a maximum emitter base voltage of 5 V. This Darlington transistor array has a minimum operating temperature of -65 °C and a maximum of 150 °C.

安富利:
Trans Darlington NPN 80V 8A 3-Pin3+Tab TO-220 Tube

Chip1Stop:
Trans Darlington NPN 80V 8A 3-Pin3+Tab TO-220 Tube

TME:
Transistor: NPN; bipolar; Darlington; 80V; 8A; 60W; TO220AB

Verical:
Trans Darlington NPN 80V 8A 60000mW 3-Pin3+Tab TO-220AB Tube

Newark:
Bipolar BJT Single Transistor, Darlington, NPN, 80 V, 60 W, 8 A, 750 hFE

儒卓力:
**NPN DARLINGTON 80V 8A TO220 **

Win Source:
TRANS NPN DARL 80V 8A TO-220
