EPCOS B72214S300K101 金属氧化物压敏电阻, 38V, 93V, 径向引线
Applications requiring protection at operating voltage levels as low as 11 volts and as high as 1100 volts with energies rated up to 15000 joules, depending on the device selected.
**Typical Protection Applications: **
* Protection of Semiconductors Diodes, Transistors, Thyristors, ICs, Etc.
* Appliances Connected to 110 V or 220 VAC
* Industrial Equipment Vulnerable to Transients on the AC Power Line Computers, Traffic Controls, Motor Controllers, Etc.
* Protection of Equipment Connected to Telephone or Signal Lines, Such as Security Systems, Railroad Equipment, Fire Alarm Systems, Etc.
* Arc Suppression Across Relay and Switch Contacts
* Power Control Equipment for Power Distribution Lines
* GFI Ground Fault Interrupters
**Features:**
* Nanosecond Switching Response Time, <15 ns, with Minimal Lead Length
* High Transient Current Capability Up to 100,000 Amps
* No Extinguishing or Follow-On Current Limitations
* Compatible with Automatic Insertion; Tape and Reel Configuration Available on S05, S07, S10 and S14 Series
**Benefits:**
* Eliminates Dangerous Voltage Transients
* Lowers Overall System Costs by Reducing Downtime and Maintenance Costs
* Improves Component and System Reliability
* Reduces EMP/RFI Interference
额定电压DC 38 V
额定电压AC 30 V
绝缘电阻 ≥10 MΩ
电容 4950 pF
额定功率 0.1 W
易燃性等级 UL 94 V-0
钳位电压 93 V
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压DC Max 350 V
额定电压AC Max 275 V
安装方式 Through Hole
封装 Disc 14mm
宽度 4.4 mm
高度 18.5 mm
封装 Disc 14mm
材质 Metal-Oxide
工作温度 -40℃ ~ 85℃
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
