EPCOS B59754B120A70. 热敏电阻, PTC, 150Ω, 25%
The is a 2-pin PTC Thermistor with lead-free terminals. This B597 series thermistor is marked with manufacturer"s logo, date code and type designation stamped on in black. Self-protecting in case of malfunction of short-circuit relay or internal short circuit of capacitor. Inrush current limiters are not damaged when directly connected to Vmax even without additional current limitation. Soldering can use rosin-type flux or non-activated flux. The soldering due to insufficient preheating may cause ceramic cracks. Suitable for over-current protection, short circuit protection, inrush current limiter charging resistor for smoothing and DC link capacitors and to replace high-power fixed resistors for capacitor charging.
Avoid contamination of thermistor surface during storage, handling and processing. Do not touch components with bare hands.
Gloves are recommended.
工作电压 440 VAC
跳闸时间 3 s
电阻 150 Ω
阻值偏差 ±25 %
跳闸电流 100 mA
保持电流Max 50 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
额定电压Max 1000 V
安装方式 Through Hole
引脚数 2
封装 Radial, Disc
宽度 10 mm
脚长度 35 mm
封装 Radial, Disc
工作温度 -40℃ ~ 125℃
包装方式 Bulk
制造应用 Safety, 安全
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
B59754B120A70 Epcos 爱普科斯 | 当前型号 | 当前型号 |
B59754B0120A070 爱普科斯 | 完全替代 | B59754B120A70和B59754B0120A070的区别 |
