BZ-3YQ69T

BZ-3YQ69T图片1
BZ-3YQ69T图片2
BZ-3YQ69T图片3
BZ-3YQ69T图片4
BZ-3YQ69T概述

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15A 125/250VAC, ENEC 16A 250VAC, 152,4mm [6in] Straight Lever Actuator with Elastomer Plunger Seal, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15 A 125/250 Vac, ENEC 16 A 250 Vac, 152,4 mm [6.0 in] Straight Lever Actuator with Elastomer Plunger Seal, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC

Product Highlights

Accepted world-wide standard "Large Basic" switch

Low operating force and differential travel

Long mechanical life up to 20,000,000 cycles at 95% survival

Elongated mounting hole for easier, more accurate mounting

Current rating ranges from 15 A to 25 A

Choice of actuation, termination and operating characteristics

Potential Applications:

Irrigation systems

Semi-trailer trucks

Timing devices

Office equipment

Test instruments

Medical/dental equipment

HVAC equipment

Manually operated devices

Valves

BZ-3YQ69T中文资料参数规格
技术参数

额定电压DC 240 V

额定电压AC 250 V

额定电流 5 A

触点类型 SPDT

额定电流Max 5 A

工作温度Max 85 ℃

工作温度Min -55 ℃

额定电压AC Max 250 V

封装参数

安装方式 Panel

外形尺寸

高度 55.7 mm

物理参数

触点材质 Silver

材质 Plastic

工作温度 -55℃ ~ 85℃

其他

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

海关信息

ECCN代码 EAR99

HTS代码 8536509055

数据手册

在线购买BZ-3YQ69T
型号: BZ-3YQ69T
描述:MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15A 125/250VAC, ENEC 16A 250VAC, 152,4mm [6in] Straight Lever Actuator with Elastomer Plunger Seal, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC
