TEXAS INSTRUMENTS BQ24210DQCR 芯片, 锂电池充电器, 10WSON
The BQ24210DQCT is a 800mA single-input single cell Li-ion solar Battery Charger targeted at space-limited portable applications. The battery is charged in three phases such as conditioning, constant current and constant voltage with an IC thermal protection and safety timer. The charge current value is programmable through an external resistor. The high input voltage range with input overvoltage protection supports low-cost unregulated adapters. The input voltage regulation loop with programmable input voltage regulation threshold make it suitable for charging from alternative power sources, such as solar panel or inductive charging pad. Furthermore, when no input source is present, the IC has a load mode to power peripherals by connecting the battery to the VBUS. Load mode has current limiting function to prevent overload.
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BQ24210DQCR TI 德州仪器 | 当前型号 | 当前型号 |
BQ24210DQCT 德州仪器 | 功能相似 | BQ24210DQCR和BQ24210DQCT的区别 |
